  • ATIK camera Infinity colori ATIK camera Infinity colori

Free shipping in most EU countries

for order at least €250

ATIK Infinity color camera

Product code: AtikInfinity-C

Be the first to review this product

Quick Overview

The CCD Atik Infinity is the first CCD camera dedicated to video astronomy that uses the Sony ICX825 sensor, evolution of ICX285, for outstanding sensitivity and Quantum Efficiency: this way you can see all your preferred deep-sky objects in real time on the computer screen!


The Atik Infinity camera has both the speed and sensitivity required for this rewarding technique. Through our new, intuitive, in-house software, the Infinity brings the wonders of the deep sky to a screen in just seconds. Live continuous stacking removes background noise so you see more of what matters, and flexible histogram adjustments make sure you never miss a detail.

Availability: In stock

Regular Price: €1,110.00

Special Price €1,085.00

22% tax incl
if you pay by bank transfer €1,052.45

Details

Video astronomy is ideally suited for use in public outreach programs and educational settings. It allows faint objects to be seen in incredible detail by all involved, and maintains that ‘at the telescope’ feeling without the need to queue up and crowd round an eyepiece. With a choice of either a mono or a colour sensor, the Infinity caters for those who prioritise absolute detail, as well as those who want to explore the universe in colour beyond the sensitivity of the unaided human eye.

The ICX825 sensor is accompanied by an excellent passive cooling system and a lightweight, compact body, perfect for use with any type of telescope! But how sensitive? Compared with the 314L + 650nm, the Infinity is very sensitive. In fact it is more sensitive to even the spectacular 460EX, making it the perfect camera for those looking for a model from the cost. The graph below shows the difference in sensitivity between the sensor ICX285 and the ICX825:



But the Infinity is not only sensible. The passive cooling system which keeps the operating temperature in a satisfactory arrangements, in this camera you can not adjust the operating temperature. Calibration speaking, the room has such a low noise that record and subtract the dark is an option rather than an obligation! With its compact body, the Infinity can also be used with Fastar / Hyperstar configurations, not adding any obstruction. Its low weight also keeps to a minimum the effort on the corrector plate. Moreover, thanks to the RJ 12 you can also use it as a guide camera.



What's included in the box?

Camera body with 1.25'' adapter

USB cable 3m

1.8-meter battery power connector

CD-ROM with drivers, software and instructions manuals (PDF)

Quickstart rapid guide

Capture software is included for camera control and data acquisition, and plug-ins are included to allow use with Astroart and Maxim DL. A universal (110-230V) power adapter is optional.

System requirements: Pentium III PC with 128MB RAM, Windows XP/Vista/Win7/Win8 (not RT), CD-ROM drive and USB 2.0 port.



Technical specifications

Type: Camera CCD non raffreddata
Sensor Color
Sensor ICX 825
Resolution 1392x1040
Sensor dimensions (mm) 9 x 6.7
Sensor diagonal (mm) 11.2
Pixels dimensions (µm) 6,45x6,45
A/D converter 16 bit
Cooling No
Readout Noise (e-) 6e
ST4 integrated autoguide port Yes
Telescope interface Female T thread (42x0,75)
Connection to PC USB 2.0
Power External 12V 1A
Backfocus (mm) 13mm ±0.5
Weight (gr.) 340
